| Features
EOM Series Veterinary Operating Microscopes using fiber-optic cable for coaxial illumination, have different working distance and magnification. They are featured for flexible handling and easy operation. They can be sued for micro-operation in ENT, dentistry, ophthalmology, gynecology and surgery.
Applications:
EOM-200S, EOM-200SB veterinary microscope: Clinic applications for ENT
EOM-200T, EOM-200TB veterinary microscope: Clinic applications for Dentistry and Ophthalmology
Dimensions
Optional
Camera
| Specifications
Model of veterinarian microscope | EOM-200S | EOM-200T | EOM-200SB | EOM-200TB |
Binocular observation | Straight | 45º Tilted | Straight | 45º Tilted |
Observation magnification | 6X | |||
Interpupillary distance | 50mm-80mm | |||
Diopter | ±5D | |||
Magnification changer | 3-step magnification change: 0.6X, 1X, 1.6X | |||
Focal length of objective | 2 objectives: F=200mm, 300mm | |||
Total magnification | 3X-12X | |||
Linear field | 60.8-15.8mm | |||
Fine focusing range | 10mm | |||
Filter | Built-in green and yellow filters | |||
Illumination system | Coaxial illumination with cold light source fiber-optic cable, brightness adjustable | |||
Lamp | 21V 150W halogen lamp (10W LED optional) | |||
Power supply | AC 220V/50Hz, or 110V/60Hz | |||
Beamsplitter | No | 50:50 Beamsplitter | ||
TV adapter | C-mount 1/3 inch CCD camera attachable | |||
Balancing arm | With 2-part arm and table mount | With 2-part arm, counterweight adjustable and can be locked. With floor stand. | ||
Optional | Objective F=250mm & F=400mm, Wall mount | Demonstrator, Camera, Photo adapter, Monitor, Objective F=250mm & F=400mm, Wall mount, Table mount
| ||
| Standard Configuration
Packing List of EOM Series Operation Microscope
A. Microscope Carton:
Arm with binocular observation unit and magnification changer 1 set
Power supply box 1 pc
Beamsplitterv 1 pc
TV adapter 1 pc
Objectives
F=200mm (fitted on the microscope) 1 pc
F=300mm 1 pc
Handle 2 pcs
Handwheel 2 pcs
Power cable 1 pc
Screwdriver 2 pcs
Fuse (3A) 2 pcs
Spare halogen lamp (21V150W) 2 pcs
User’s manual 1 copy
Base Carton
Base with wheels 1 set
Column 2 pc
Threaded cover 1 pc
| Optional configuration
Demonstrator 1 pc
Objectives
F=250mm 1 pc
F=400mm 1 pc
