| Features
Microhematocrit centrifuge can be used to determine hematocrit value and separate the micro-blood from micro-solution.
Microprocessor control and DC brushless motor, which is stable and noiseless during operation.
The parameters can be freely revised during a run.
RCF value can be calculated automatically, unique RCF Key for convenient observation.
Seconds display if the centrifugation time is less than 1 min.
The protective functions of self-diagnose and overspeed for better safety.
Front
Detail
Part
| Specifications
Model | TG12M |
Order No. | 160000 |
Max. Speed | 12000rpm |
Max. RCF | 14800xg |
Max. Capacity | 36-place microhematocrit rotor |
Speed Accuracy | ±30rpm |
Time Setting Range | 1min to 99min |
Noise | <62dB(A) |
Power Supply | AC 110~220V±10%, 50/60Hz |
Total Power | 300W |
Dimension (WxDxH) | 330x390x300mm |
Package (WxDxH) | 395x650x340mm |
Net Weight | 25kg |
| Optional configuration
a) Code 854200: Capacity: 36-place, Max. Speed :12000rpm, Max. RCF: 14800xg
b) Code 852700: Capacity: 24-place, Max. Speed :12000rpm, Max. RCF: 14800xg
c) Code 852800: Capacity: 12-place, Max. Speed :12000rpm, Max. RCF: 14800xg
| About Us
SHINOVA, a well-known animal health brand in the world.
SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.
For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
