| Features
JX820D AC/DC Emergency Aspirator is the latest portable AC/DC suction unit. It is specially used for secretion, blood, vomitus and mucus removal of the patient who have undergone tracheostomy or had the trachea blocked, and for emergency treatment to a respiratory tract patient in hospital, first-aid teams, or social medical services, especially for a patient who is transported by vehicle or is in a place without AC/DC power supply.
Long life piston cylinder which requires no lubrication or daily maintenance produces no pollution to the environment.
Provided with three kinds of electrical sources, AC 100V~240V 50/60Hz, external DC12V, and internal battery, it can be conveniently used in many places.
The internal battery is charged with constant voltage and limited current while the unit is working or being attached to AC 100V~240V 50/60Hz or external DC 12V power supply. The capacity of the battery is respectively indicated by green, yellow and red neons.
Overflow protection device can safely and efficiently prevent the liquid from entering into pump. Bottles made of plastic material are transparent, durable and convenient for cleaning.
Body made of plastic material is handy and beautiful. The wall-mounting frame makes it widely used in the room, on vehicle and conveniently hung on the side of the wheelchair.
| Specifications
Max vacuum: 0.08MPa(600mmHg)
Vacuum range: 0.02MPa(150mmHg)~Max. vacuum
Flow rate: 20 L/min
Jar capacity: 1000ml (PC)
Noise: 65 dB(A)
Operating voltage: DC 12V or AC 100V~240V, 50/60Hz
Power input: 110VA
Battery duration on full charge: 30min
G.W.: 5.5kg; N.W.: 4kg
Packing dimension: 40.5cm 20cm 36cm
| Standard Configuration
Fuse (RF1 φ5×20 10A/250V) 2 pc
Air Filter 2 pc
Hand Switch 1 pc
Power Adapter 1 pc
Suction hose 1 pc
Car power line 1 pc
Suction sputum tube(Disposable use) 2 pc
| About Us
SHINOVA, a well-known animal health brand in the world.
SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.
For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
