Electric Suction Unit

  • YX932D

  • SHINOVA

Availability:
Quantity:


|  Features

Model YX932D Electric Suction Unit, intended for extracting various mucus such as purulence, blood and phlegm from body cavity or wound in hospitals or center of social medical service, is a mobile suction unit with a high flow, high vacuum and a novel style. It can satisfy most demands in operating rooms.

  • An oil-less vacuum pump, double piston cylinder with a high flow, high vacuum, the pump needs maintenance free.

  • Move smoothly and freely with a swing-type pull handle; the accessory-case for placing foot-switch and power supply wire makes it convenient for movement or storage.

  • Large-bore and large capacity bottles with stopper having sealing ring, easy to clean and to open or close.

  • The overflow protection device is intended to prevent liquid or solid particles form entering the intermediate tubing and pump.

  • Transparent non-toxic PVC hoses and unique connections are easy to observe and link.

  • The level of vacuum required in clinic can be controlled by adjusting the regulator knob, and a synchronized indication on the vacuum meter.

  • Stability and durability, low noise, safe and reliable to operate.


8


DSC01675


DSC01688



|  Specifications

Max vacuum: ≥0.09MPa (680mmHg)

Adjustable vacuum range: 0.02MPa(150mmHg)~Max.

Flow rate: ≥32L/Min

Noise: ≤60dB(A)

Storage bottles: 2500ML×2

Power supply: AC220V/50Hz (110V customized)

Input power: 150VA

G.W./N.W.: 14/12kg

Packing dimension: 40cm×38cm×47cm


YX932D_A01-名称标注


|  About Us

未标题-1

logo

SHINOVA, a well-known animal health brand in the world.

SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.

For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
