AneMotor
SHINOVA
| Quantity: | |
|---|---|
| Features
Turbo-driven design, no need of high-pressure oxygen cylinder, just an oxygen concentrator to make it work as veterinary anesthesia workstation
9" color touch-screen display
High-quality aluminum trolley equipped with your veterinary anesthesia machine
Intelligent calculation by inputting animal weight to calculate other parameters automatically
With pressure, volume, manual and other breathing modes, meet different clinical needs
Built-in high-precision sensor and valve control technology ensure the safety, stability and accuracy of pressure, flow and volume monitoring
Equipped with high-precision anesthesia vaporizer
Integrated circuit, easy to install and remove
Non-breathing circuit interface at the front of the unit is convenient for small animals
Built-in proportional valve control system
Triple visual and audio alarm system to ensure safety during surgery
Wide application to animals of different weights and sizes in this veterinary anesthesia system
Oxygen concentrator is optional
| Specifications
Anesthesia Main Unit:
Working mode: Cyclic breathing and non-cyclical bretahing
Driving mode: Electrical drive and electronic control (Turbo-driven)
Anesthesia gas source switch: Start or stop gas source
Pressure gauge: oxygen source pressure, oxygen working pressure
Anesthesia vaporizer: lsoflurane, sevoflurane, enflurane, halothane
Oxygen flush: 25L/min~75L/min
Flowmeter: double tube flowmeter, 0~1L/min, 1~10L/min
Application: 0.8-120kg animals
Anesthesia Ventilator:
Ventilation mode: VCV, PCV,Spont, Manual, Demo
Tidal volume: Automatic 3-1600ml, manual 5-1600ml
Bellow: 0-300ml, 300-1500ml
Waveform: Pressure, flow, volume
Loop: Pressure-volume, flow-volume
Breathing rate: 1~100bpm
1:E: 9.9:1 to 1:9.9
Inhalation time: 0.1~10s
Inspiratory pause: 0-50%
PEEP: Off, 3~20cmH2O
Pressure support: 0~60cmH2O
Pressure control: 5~60cmH2O
Flow rate trigger: 0.5~20L/min
Pressure trigger: -1~20cmH2O
Anesthesia Vaporizer:
With pressure, flow and temperature automatic compensation
Concentration range: lsoflurane: 0.2 to 5%, Sevoflurane: 0.2 to 8%, Halothane: 0.2 to 5%
Flow rate range: 0.2 to 15L/min
Suspension type: Selectatec
Anesthetic volume: 340ml (dry cavity), 300ml (wet cavity)
Monitoring Parameters:
Tidal volume, breathing rate, spontaneous breathing rate, l:E, driving gas pressure, spontaneous ventilation volume, minute ventilation volume, peak/airway/average airway pressure, PEEP end-tidal pressure, inspiratory platform pressure, FiO2, EtCO2
Alarm Parameters:
Tidal volume, minute ventilation volume, breathing rate, airway pressure, peak airway pressure, apnea alarm, supply pressure failure alarm, power supply alarm, pipeline falling or leakage, low air gas pressure, PEEP end-tidal pressure, FiO2(optional), FiCO2(optional)
| About Us
SHINOVA, a well-known animal health brand in the world.
SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.
For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
