| Features
Random access and direct reading system
New concept and more friendly software
Automatic washing station for both sample and reagent probe
Liquid level detection, collision protection for sample /reagent probe
Reliable cooling system for reagent chamber
8 channels automatic cuvette washing system
Perfect self-checking and alarm function
Bar code reader and lSE Module available on request
Designed with environmental protection concept
| Specifications
Throughput: 260 tests/hour (without ISE)
Assay type: random access with direct reading system
Methodology: end point, kinetic, fixed time, Immunoturbidimetry, single wavelength, bich romatic, multi-standard, reagent blank, serum blank etc.
Sample volume: 1-100ul, equipped with high-precision diluter, 0.1ul/step
Reagent volume: 1-500ul,0.1ul/step
Sample position: 50 positions. Including standard, control and STAT, either serum cup or primary tube available
Reagent position: 47 positions: R1:26, R2:21
Reagent/Sample probe: with liquid level sensor, collision sensor, automatically detect reagent residue in reagent bottle
Mixing system: one independen t mixer
Reaction time: 10 minutes
Cuvette: 90 high quality UV-transmitted plastic cuvettes, and quartz glass cuvettes available on request
Washing: 8 channels automatic washing system; waste liquid collected by high concentration and l ow concentration respectively; automatically dry cuvette; water consumption is 2-4L/H
Alarm: automatic alarm for malfunction( collision, reagent/sample insufficiency, full waste container etc.)
Standard: linear, non-linear, multi standard, K factor
Sample dilution/retest: sample can be diluted and retested if result is out of range or sample is insufficient
Light source: halogen l amp
Wavelength: 330nm-850nm ; standard equipped with 8 filters, 4 more filters available on request
Absorbance drift : ≤0.002
Measure range: 0.1000～3.500
Temperature drift: ±0.1℃
Garry over: ≤0.01%
Precision: 0.00010.D
Auto blank function: auto zero setting and deduct/record blank value for each cuvette to ensure accuracy
Emergency test: emergency sample test prior
Beliable accuracy: equipped with automatically test error diagnosis and correcting, automatic maintenance etc.
Control/Calibration: with patented auto control and calibration management functions
Bar code: bar code( sample/reagent) available on request
Data storage: more than 5000 items and 2 mill ion results can be ed ited and stored
Software: stronger and more convenient software with multiple languages
Printer: multiple report formats available
Power supply: 220V or 110V, 50Hz or 60Hz
Dimension: 85×72×54(cm)
Weight: 50.00kgs
| About Us
SHINOVA, a well-known animal health brand in the world.
SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.
For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
