Moni 8DV
shinova
| Quantity: | |
|---|---|
| Features
Super ability in against electrosurgical interference. Neither in cutting nor in burning, ECG waveform and HR can be influenced, very short recovering time after defibrillation, especially suitable for use in emergency or operating room.
Unique thoracic impedance & nasal tube double modes respiration test method (when animals can not lie quietly, only nasal tube respiration can detect the right respiration waveform and respiration rate).
12.1" color TFT LCD screen, High brightness, Wide viewing, 8 waveforms can be displayed on the same screen. Lightness and volume are adjustable independently.
Streamlined outline design with sense of the times & foldable handle.
Multi-language interface selection: English, Spanish, French, Russian, Arabic, Portuguese, Italian, Turkish, Chinese, etc.
User-friendly and man-machine dialogue interface with pop-up menus, dialogue boxes, rotary mouse and etc.
Low-power consumption design with standby mode, rechargeable high-energy built-in battery.
Advanced digital technology, accurately measure SpO2 in low perfusion situation.
Huge history trend data storage up to 360 hours
Drug calculation, ST-segment detection, pace maker and arrhythmia analysis.
5 kinds of fixed display format includes OxyCRG diagram, 7-lead ECG waveform, big-font mode, etc.; 5 kinds of user-defined display format.
3-level audible alarm, visual alarm and apnea alarm available; Alarm limits are adjustable.
Suitable for adult, pediatric and neonate animals.
Applications in bedside and delivery monitoring; Widely used in in-patient room, emergency room, operation room, etc.
WAN communication function to network with central monitoring system and make long-distance monitoring, diagnosis, maintenance and software upgrade possible.
Printing of data, waveform, trend tables and trend diagram.
| Specifications
ECG
Input: 3-lead/5-lead ECG cable
Lead selection: I, II, III, AVR, AVL, AVF, V
Gain selection: x1/4, x1/2, x1, x2, x4 and automatic
Sweep speed: 3.125, 6.25, 12.5, 25, 50mm/s
Measurement range: 15bpm~380bpm,
Calibration: ±1 mv
Accuracy: ±1%
NIBP
Philosophy: Oscillometric method
Measurement type: Adult, Pediatric and Neonate
Measurement parameter: Systolic, Diastolic, Mean
Measurement method: Manual, Automatic, Continuous measurement
Unit: mmHg/kPa selection
Accuracy: ±3mmHg or ±2%
SpO2
Display type: Waveform, Data
Measurement range: 0~100%
Accuracy: 1%
Pulse rate range: 30~250bpm
Accuracy: ±1 bpm
Resolution: 1 bpm
Temperature
Number of channels: 2
Measurement range: 0℃~ 50℃
Resolution: 0.1℃
Display: T1, T2, ΔT
Unit: ℃/℉ selection
Respiration Rate
Measurement range: 0~156 bpm
Accuracy: ±1 bpm
Resolution: 1 bpm
IBP (Optional)
Measurement range: -10~300 mmHg
Number of channel: 2 channel
Accuracy: ±1mmHg or ±2%
Pressure tag: ART, CVP, RVP, LAP, RAP, PAP, ICP, LVP
ETCO2 (Optional)
Measurement type: Main/Side stream
Measurement range: 0%~19.7%; 0~150 mmHg; 0~20 kpa
Accuracy: 0~40 mmHg ±2 mmHg
41~70 mmHg ±5%
71~100 mmHg ±8%
101~150 mmHg ±10%
Cardiac Output (Optional)
Measuring Method: Thermodilution
Blood temperature measurement and alarm range: 23 ℃~43 ℃
Unit: degrees Celsius ℃ or Fahrenheit ℉
Error: ±0.2℃
Resolution: 0.1℃
Cardiac output measurement range: 0.1 L/min~20.0 L/min
Error: ±0.2 L/min or ±5%
Anesthesia Gas Analysis (Optional)
Method: Infrared Absorption
Gas Sorts: CO2, N2O, Des, Iso, Enf, Sev, Hal and optional O2
Measurement range: CO2: 0~30%, N2O: 0~105%, O2: 0~105%, Iso, Enf, Hal: 0~30%, Sev: 0~30% Des: 0~30%
Data input: Fi and Et values
Optional agent mixture detection
Power Requirement
Working voltage: 100~240VAC, 50/60Hz
Power rate: 80 VA
Battery backup: 3 hours as option
| Standard Configuration
Main unit with standard 6-parameter veterinary accessories (ECG, NIBP, SpO2, RESP, TEMP, HR/PR)
Rechargeable battery
| Optional configuration
2-IBP, EtCO2 (Mainstream or Sidestream)
CO
AG (Anesthesia Multigas Module)
Built-in Printer
Mobile Trolley
Wall Mount
Touch Screen
12V Power Supply for Ambulance Use
Carrying Bag
Wireless Network
| About Us
SHINOVA, a well-known animal health brand in the world.
SHINOVA, based in Shanghai, is a professional veterinary equipment manufacturer and veterinary solutions provider primarily for animal hospitals and scientific research institutes.
For decades global operations, Shinova has dedicated itself to providing advanced veterinary techniques and medical solutions to tens of thousands of animal hospitals (including veterinary hospitals and equine hospitals) and veterinary schools (including veterinary teaching and animal experiments) in Europe, America, Australia, China, etc.
